Sockets and light switches are among the most-touched fixtures in any home, yet they are also among the most regulated. Get the positions or specification wrong and you face anything from a failed inspection to a genuine fire risk. This guide covers the main product types, recommended mounting heights, and the Part P rules that govern when a qualified electrician must be involved.

How UK Regulations Apply

Electrical work in dwellings falls under Part P of the Building Regulations (England and Wales; Scotland has equivalent rules in Technical Handbook Section 4, while Northern Ireland has no Part P equivalent, its Technical Booklet P covers sanitary appliances).1 Only three jobs are notifiable: a new circuit, a replacement consumer unit, and any addition or alteration to existing circuits in a special location, meaning the zone around a bath or shower, or a room containing a swimming pool or sauna heater.2 Notifiable work must be certified by a registered competent person, by a registered third-party certifier, or by a building control body.2 The authorised electrical schemes in England and Wales are BESCA, Blue Flame Certification, Certsure (which runs NICEIC), NAPIT and OFTEC.3 Minor like-for-like replacements (swapping a damaged socket in a living room for the same type) are generally permitted as DIY, but the work must still comply with BS 7671 (the IET Wiring Regulations, 18th edition, now BS 7671:2018+A4:2026).4

Bathroom rules

Socket-outlets should be at least 2.5 m from the edge of a bath tub or shower tray (the boundary of zone 1), unless they are SELV socket-outlets or shaver supply units complying with BS EN IEC 61558-2-5.5 Approved Document P’s 2013 diagram still shows the older figure of 3 m.2 Standard sockets, even switched ones, are not allowed closer. Separately, the space 600 mm horizontally and 2,250 mm vertically from a bath or shower is a special location, in which altering an existing circuit becomes notifiable.2

Socket Types

Standard 13 A Switched Sockets

The workhorse of UK domestic wiring. Available in single (one outlet) and double (two outlets) configurations, and in three physical profiles:

  • Flush, backbox recessed into the plasterboard or masonry, faceplate sitting flush with the wall. Neater appearance; a 35 mm deep back box is the usual choice, and USB sockets generally need one.
  • Surface (patress), back box sits proud of the wall. No chasing required; often used in garages and utility rooms.
  • Slimline, typically 25 mm deep; requires a shallower back box. Useful where a full 35 mm recess is not possible (e.g., dot-and-dab plasterboard over a thin cavity).

A plain white moulded double switched socket costs about £1.65–£5 at the trade counters; brushed steel, chrome and matt black plates cost more.

USB Sockets

Increasingly standard in kitchens and bedrooms. Available with USB-A only, USB-A + USB-C, or USB-C only ports alongside the 13 A outlets. Combined units rated at 3.1 A total USB output are common; some fast-charge models offer USB-C at up to 30 W. They occupy the same footprint as a standard double socket, but most need a 35 mm deep back box.

Specialist Sockets

  • Unswitched fused connection units (FCUs), for permanently wired appliances (extractor fans, shaver points).
  • Outdoor sockets, IP-rated (IP44 is common for sheltered positions, and IP65 or higher suits exposed ones). Like any socket-outlet rated up to 32 A, they need 30 mA RCD protection.6
  • Floor sockets, spring-loaded, IP20 or IP54 rated, suitable for island units and home offices.

Light Switch Types

TypeDescriptionTypical cost (per unit)
1-gang 1-waySingle switch, one location£3–£12
1-gang 2-waySingle switch, two locations (e.g., top/bottom of stairs)£4–£15
2-gang 1-wayTwo switches on one plate£5–£14
IntermediateThree-location switching; fits between two 2-way switches£8–£25
Dimmer (leading edge)For traditional incandescent/halogen (now rare)£15–£50
Dimmer (trailing edge / LED)Required for most modern LED drivers£20–£60
Smart switchWifi/Zigbee; requires neutral wire in most cases£30–£80

Dimmer Compatibility

Most dimmable LED lamps need a trailing-edge (capacitive) dimmer. A leading-edge dimmer used with LEDs often causes flickering, buzzing, and premature lamp failure. Check the dimmer’s minimum load rating, some require at least 25 W on the circuit, which can be hard to reach with very efficient LEDs.

In a new dwelling in England, Approved Document M requires switches and sockets serving habitable rooms to have their centre line 450–1200 mm above floor level, and consumer units to be mounted with their switches 1,350–1,450 mm above floor level.7 In a wheelchair user dwelling (optional requirement M4(3)), switches, sockets and controls sit lower, with their centre line 700–1,000 mm above floor level.7 Existing homes are not bound by those figures, but they are what most electricians and building control inspectors work to:7

FittingRecommended height (to centre)Notes
Wall sockets (general)450 mm from finished floorAvoids bending; suits wheelchair users
Kitchen worktop sockets150 mm above worktop surfaceRoughly 1,050 mm from floor
Light switches1,200 mm from finished floorStandard; some older properties use 1,350 mm
Switches (wheelchair user dwellings)700–1,000 mmApproved Document M figure for M4(3) wheelchair user dwellings
Consumer unit1,350–1,450 mmApproved Document M figure for new dwellings

In an existing home these are guidelines rather than absolute requirements, but deviating significantly may be flagged during a building control inspection or when selling.

Installation Costs

JobTypical cost (2026, England)
Supply & fit double socket (new spur)£120–£180
Supply & fit double socket (like-for-like)£60–£100
Add USB double socket£100–£160
New lighting circuit (8 outlets)£350–£600
Replace dimmer switch£80–£140
Install outdoor socket (RCD protected)£180–£300

Labour rates vary regionally, and London and the South East usually cost more. Always obtain at least two quotes and check the electrician’s scheme registration before proceeding.

What You Can DIY

In England and Wales, the following are generally permissible DIY (subject to the work meeting BS 7671):

  • Replacing like-for-like fittings, swapping a standard socket for another standard socket on the same circuit, for example; replacements are not notifiable anywhere in the home, kitchens and gardens included.2
  • Installing a spur from an existing ring main anywhere outside the special location around a bath or shower, provided the new socket has 30 mA RCD protection, which BS 7671 requires for socket-outlets rated up to 32 A.2

You cannot self-certify new circuits as a homeowner; they must be certified by a registered competent person, by a registered third-party certifier, or by a building control body after a building notice is submitted to your local authority before work begins.2

Choosing Finishes

Sockets and switches are available in polished chrome, brushed steel, antique brass, matt black, and plain white. Matt black has become popular in recent years and usually costs more than standard white. Brushed steel sits between the two. Where multiple fittings are visible from the same point, keep the finish consistent, mixing polished chrome with brushed steel in the same room reads as an afterthought.

Common Mistakes to Avoid

  • Overloading a spur, an unfused spur from a ring main may feed only one single or one double socket-outlet. To add more, take the spur through a fused connection unit or run a new circuit.
  • Wrong back box depth, a box too shallow for the accessory and its cables leaves the faceplate sitting proud or cracks it. A 35 mm box is the safe default for double and USB sockets; slimline plates suit 25 mm boxes.
  • Ignoring RCD protection, the 18th edition Wiring Regulations require additional protection by a 30 mA RCD for socket-outlets rated up to 32 A.6 If your consumer unit is old and lacks RCDs, consider an upgrade before adding sockets.
  • No earth on metal faceplates, decorative metal switches and sockets must be earthed. If you are fitting a chrome switch to an old two-core-and-earth cable, ensure the earth conductor is properly connected to the faceplate earth terminal.
